nRF52840 M.2 Module w/ PCB Antennas

Regular price
$14.90
Sale price
$14.90
Regular price
$14.90
Sold out
Unit price
per

Description

nRF52840 M.2 Module is a removable module designed and built to meet the multiprotocol connectivity, security and ease-of-use requirements of your next embedded design. Based on the nRF52840 SoC, it has protocol support for Bluetooth 5, Bluetooth mesh, Thread, Zigbee, 802.15.4, ANT and 2.4 GHz proprietary stacks.

The module comes with an M.2 (also known as NGFF - Next Generation Form Factor) Key-E form factor, 64Mbit QSPI flash memory, RGB LED and U.FL/I-PEX MHF antenna connectors, that will simplify and minimize the development cycle and deployment of your end-product helping to accelerate its time-to-market.

Key Features

  • Nordic Semiconductor nRF52840 SoC
    • 64 MHz Arm® Cortex-M4 with FPU
    • 1 MB Flash + 256 KB RAM
    • Bluetooth 5, Bluetooth mesh, Thread, Zigbee, 802.15.4, ANT and 2.4 GHz proprietary
    • Arm TrustZone® Cryptocell 310 Security Subsystem
    • Integrated USB 2.0 Full-speed Controller
    • QSPI/SPI/TWI/I²S/PDM/QDEC/ADC support
    • Integrated NFC-A Tag
  • M.2 Key-E Form Factor
  • Ultra low power 64Mbit QSPI flash memory
  • User programmable RBG LED
  • U.FL/I-PEX MHF Antenna Connectors
  • 2.4 GHz and NFC cabled PCB Antennas
  • 3.3V IO Operating Voltage
  • Shipped with Python Interpreter firmware
  • Dimensions: 22.00 x 30.00 x 2.1 mm

Targeted Applications

  • IoT Multi-Protocol Devices
  • Lighting
  • Connected Home
  • Building Automation and Security
  • Computer peripherals and I/O

Hardware Diagram

The hardware diagram of the nRF52840 M.2 Module is shown below:

Download the full hardware diagram as PDF here.

Included in the Box

  • 1x nRF52840 M.2 Module
  • 1x 2.4 GHz Cabled PCB Antenna
  • 1x NFC Cabled PCB Antenna

Getting Started

The nRF52840 M.2 Developer Kit is available for the nRF52840 M.2 Module evaluation and development. See below for available documentation:

Design Resource

Package details

Dimensions 80mm x 55mm x 13mm
Weight G.W 15g
